Cisco ONS 15454 DWDM Reference Manual

A-20
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.6.3 4MD-xx.x Card Specifications
The 32DMX-O card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.6.3 4MD-xx.x Card Specifications
The 4MD-xx.x card optical specifications are listed in Table A-5.
Note For power specifications, see Table A-2 on page A-6.
Table A-4 32DMX-O Optical Specifications
Parameter Note Condition Min Max Unit
Receive (Rx) filter
shape (–1 dB
bandwidth)
All SOP and within
whole operating
temperature range
In 1/32—Out BOL +/–180 +/–300 pm
In 1/32—Out EOL +/–160 +/–300 pm
Insertion loss All SOP and within
whole operating
temperature range
In 1/32—Out BOL 4 8.0 dB
In 1/32—Out EOL 4 8.5 dB
VOA dynamic range — — 25 — dB
Maximum optical
input power
— — 300 — mW
Table A-5 4MD-xx.x Optical Specifications
Parameter Note Condition Min Max Unit
Trx filter shape
(–0.5 dB bandwidth
TrxBW
2
)
All SOP and within
whole operating
temperature range
COM Rx—xx.xx Tx
COM Rx—yy.yy Tx
COM Rx—zz.zz Tx
COM Rx—kk.kk Tx
+/–180 — pm
xx.xx Rx—COM Tx
yy.yy Rx—COM Tx
zz.zz Rx—COM Tx
kk.kk Rx—COM Tx
Insertion loss
demultiplexer
section
All SOP and within
whole operating
temperature range
COM Rx—xx.xx Tx — 1.9 dB
COM Rx—yy.yy Tx — 2.4 dB
COM Rx—zz.zz Tx — 2.8 dB
COM Rx—kk.kk Tx — 3.3 dB

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
