Cisco ONS 15454 DWDM Reference Manual

1-59
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 1 Shelf Assembly Hardware
1.15.4 TL1 Craft Interface Installation
1.15.4 TL1 Craft Interface Installation
You can use the craft pins on the ONS 15454 ANSI backplane or the EIA/TIA-232 port on the
TCC2/TCC2P faceplate to create a VT100 emulation window to serve as a TL1 craft interface to the
ONS 15454 ANSI. Use a straight-through cable to connect to the EIA/TIA-232 port. Table 1-15 shows
the pin assignments for the CRAFT pin field.
Note You cannot use the craft backplane pins and the EIA/TIA-232 port on the TCC2/TCC2P card
simultaneously.
Note To use the serial port craft interface wire-wrap pins on the backplane, the DTR signal line on the
backplane port wire-wrap pin must be connected and active.
1.16 Cards and Slots
ONS 15454 cards have electrical plugs at the back that plug into electrical connectors on the shelf
assembly backplane. When the ejectors are fully closed, the card plugs into the assembly backplane.
Figure 1-55 shows card installation for an ONS 15454 ANSI shelf.
Table 1-14 LAN Pin Assignments
Pin Field Backplane Pins RJ-45 Pins
LAN 1
Connecting to data circuit-terminating
equipment (DCE
1
, a hub or switch)
1. The Cisco ONS 15454 ANSI is DCE.
B2 1
A2 2
B1 3
A1 6
LAN 1
Connecting to data terminal equipment
(DTE) (a PC/workstation or router)
B1 1
A1 2
B2 3
A2 6
Table 1-15 Craft Interface Pin Assignments
Pin Field Contact Function
Craft A1 Receive
A2 Transmit
A3 Ground
A4 DTR

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
