Cisco ONS 15454 DWDM Reference Manual

2-16
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 2 Common Control Cards
2.5 MS-ISC-100T Card
Table 2-11 lists the MS-ISC-100T port assignments.
Figure 2-5 shows the card faceplate.
Caution Shielded twisted-pair cabling should be used for interbuilding applications.
Table 2-11 MS-ISC-100T Card Port Assignments
Port Description
DCN 1and DCN 2 Connection to the network
SSC1 to SSC7 Connection to subtending shelves
NC Connection to TCC2/TCC2P using a cross-over cable
PRT Connection to the PRT port of the redundant MS-ISC-100T

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
