Cisco ONS 15454 DWDM Reference Manual

15-40
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 15 Management Network Connectivity
15.5 Routing Table
– pdcc0—An SDCC or RS-DCC interface, that is, an OC-N/STM-N trunk card identified as the
SDCC or RS-DCC termination.
– lo0—A loopback interface.
Table 15-9 shows sample routing entries for an ONS 15454.
Entry 1 shows the following:
• Destination (0.0.0.0) is the default route entry. All undefined destination network or host entries on
this routing table are mapped to the default route entry.
• Mask (0.0.0.0) is always 0 for the default route.
• Gateway (172.20.214.1) is the default gateway address. All outbound traffic that cannot be found in
this routing table or is not on the node’s local subnet is sent to this gateway.
• Interface (motfcc0) indicates that the ONS 15454 Ethernet interface is used to reach the gateway.
Entry 2 shows the following:
• Destination (172.20.214.0) is the destination network IP address.
• Mask (255.255.255.0) is a 24-bit mask, meaning all addresses within the 172.20.214.0 subnet can
be a destination.
• Gateway (172.20.214.92) is the gateway address. All outbound traffic belonging to this network is
sent to this gateway.
• Interface (motfcc0) indicates that the ONS 15454 Ethernet interface is used to reach the gateway.
Entry 3 shows the following:
• Destination (172.20.214.92) is the destination host IP address.
• Mask (255.255.255.255) is a 32 bit mask, meaning only the 172.20.214.92 address is a destination.
• Gateway (127.0.0.1) is a loopback address. The host directs network traffic to itself using this
address.
• Interface (lo0) indicates that the local loopback interface is used to reach the gateway.
Entry 4 shows the following:
• Destination (172.20.214.93) is the destination host IP address.
• Mask (255.255.255.255) is a 32 bit mask, meaning only the 172.20.214.93 address is a destination.
• Gateway (0.0.0.0) means the destination host is directly attached to the node.
• Interface (pdcc0) indicates that a DCC interface is used to reach the destination host.
Entry 5 shows a DCC-connected node that is accessible through a node that is not directly connected:
• Destination (172.20.214.94) is the destination host IP address.
Table 15-9 Sample Routing Table Entries
Entry Destination Mask Gateway Usage Interface
1 0.0.0.0 0.0.0.0 172.20.214.1 265103 motfcc0
2 172.20.214.0 255.255.255.0 172.20.214.92 0 motfcc0
3 172.20.214.92 255.255.255.255 127.0.0.1 54 lo0
4 172.20.214.93 255.255.255.255 0.0.0.0 16853 pdcc0
5 172.20.214.94 255.255.255.255 172.20.214.93 16853 pdcc0

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
