Cisco ONS 15454 DWDM Reference Manual

18-8
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 18 SNMP
18.6.3 Generic Threshold and Performance Monitoring MIBs
Threshold values can be provided in 64-bit and 32-bit formats. (For more information about 64-bit
counters, see the “18.11.2 HC-RMON-MIB Support” section on page 18-21.) The 64-bit values in
cerentGenericPmThresholdHCValue can be used with agents that support SNMPv2. The two 32-bit
values (cerentGenericPmThresholdValue and cerentGenericPmThresholdOverFlowValue) can be used
by NMSs that only support SNMPv1.
Due to the 64-bit counter, the negative values for cerentGenericPmThresholdHCValue are displayed as
large positive integers. If the cerentGenericPmThresholdOverFlowValue is less than zero, it indicates
that the cerentGenericPmThresholdHCValue is representing a negative value.
The objects compiled in the cerentGenericPmThresholdTable are shown in Table 18-4.
The second table within the MIB, cerentGenericPmStatsCurrentTable, compiles the current performance
monitoring (PM) values for the monitor types. The table is indexed based on interface index
(cerentGenericPmStatsCurrentIndex), monitor type (cerentGenericPmStatsCurrentMonType), location
(cerentGenericPmStatsCurrentLocation) and time period (cerentGenericPmStatsCurrentPeriod). The
syntax of cerentGenericPmStatsCurrentIndex is type cerentLocation, defined in CERENT-TC.mib. The
syntax of cerentGenericPmStatsCurrentMonType is type cerentMonitor, defined in CERENT-TC.mib.
The syntax of cerentGenericPmStatsCurrentPeriod is type cerentPeriod, defined in CERENT-TC.mib.
The cerentGenericPmStatsCurrentTable validates the current PM value using the
cerentGenericPmStatsCurrentValid object and registers the number of valid intervals with historical PM
statistics in the cerentGenericPmStatsCurrentValidIntervals object.
PM values are provided in 64-bit and 32-bit formats. The 64-bit values in
cerentGenericPmStatsCurrentHCValue can be used with agents that support SNMPv2. The two 32-bit
values (cerentGenericPmStatsCurrentValue and cerentGenericPmStatsCurrentOverFlowValue) can be
used by NMS that only support SNMPv1.
Due to the 64-bit counter, the negative values for cerentGenericPmStatsCurrentHCValue are displayed
as large positive integers. If the cerentGenericPmStatsCurrentOverFlowValue is less than zero, it
indicates that the cerentGenericPmStatsCurrentHCValue is representing a negative value.
The cerentGenericPmStatsCurrentTable is shown in Table 18-5.
Table 18-4 cerentGenericPmThresholdTable
Index Objects Information Objects
cerentGenericPmThresholdIndex cerentGenericPmThresholdValue
cerentGenericPmThresholdMonType cerentGenericPmThresholdOverFlowValue
cerentGenericPmThresholdLocation cerentGenericPmThresholdHCValue
cerentGenericPmThresholdPeriod —
Table 18-5 32-Bit cerentGenericPmStatsCurrentTable
Index Objects Informational Objects
cerentGenericPmStatsCurrentIndex cerentGenericPmStatsCurrentValue
cerentGenericPmStatsCurrentMonType cerentGenericPmStatsCurrentOverFlowValue
cerentGenericPmStatsCurrentLocation cerentGenericPmStatsCurrentHCValue
cerentGenericPmStatsCurrentPeriod cerentGenericPmStatsCurrentValidData
— cerentGenericPmStatsCurrentValidIntervals

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
