A-81
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.10 Mesh Patch Panel Specifications
• Environmental
–
Power consumption: 50.00 W (maximum), 1.11 A at –48 V, 136.6 BTU/hr
• Dimensions
–
Height: 12.992 in. (330 mm)
–
Width: 10GE_XP and 10GE_XPE: 0.921 in. (23.4 mm)
GE_XP and GE_XPE: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
–
Depth: 9.448 in. (240 mm)
–
Depth with backplane connector: tbd in. (tbd mm)
–
Weight not including clam shell: 10GE-XP, 1.04 kg; GE-XP, 1.36 kg.
A.10 Mesh Patch Panel Specifications
This section provides specifications for the PP-MESH-4 and PP-MESH-8 patch panels.
A.10.1 PP-MESH-4 Patch Panel Specifications
The PP-MESH-4 patch panel optical specifications are listed in Table A-47.
The PP-MESH-4 patch panel has the following additional specifications:
• Environmental
Table A-47 PP-MESH-4 Patch Panel Optical Specifications
Parameter Note Condition Min Max Unit
Wavelength range — — 1530 1570 nm
Insertion loss
1
2
1. Under all SOPs and all operating environmental conditions
2. Values are referenced with connector loss (LC=0.3 dB, MPO=0.5dB)
— In all the wavelength
ranges
(local ADD or test
access RX to EXP TX,
COM RX to EXP TX,
COM RX to test access
TX)
—7.5dB
Insertion Loss
Uniformity
1 2
— In all the wavelength
ranges
—0.9dB
Polarization
dispersion loss (PDL)
1
—— —0.3dB
Polarization mode
dispersion (PMD)
1
—— —0.1dB
Optical Return Loss
1
—— 50—dB
Directivity
1
—— 50—dB
