Cisco ONS 15454 DWDM Reference Manual

5-18
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 5 Multiplexer and Demultiplexer Cards
5.4 32DMX-O Card
Figure 5-14 32DMX-O Faceplate
For information on safety labels for the card, see the “5.2.2 Class 1M Laser Product Cards” section on
page 5-10.
Figure 5-15 shows a block diagram of the 32DMX-O card.
32DMX-0
FAIL
ACT
SF
30.3 - 36.638.1 - 44.546.1 - 52.5
TX
54.1 - 60.6
RX
COM
MON
145935

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
