Chapter 7 Reconfigurable Optical Add/Drop Cards
7.12.5 40-WXC-C Card-Level Indicators
7.12.5 40-WXC-C Card-Level Indicators
The 40-WXC-C card has three card-level LED indicators described in Table 7-40.
B38.1 38.1 194.9 1538.19
38.9 194.8 1538.98
39.7 194.7 1539.77
40.5 194.6 1540.56
41.3 194.5 1541.35
B42.1 42.1 194.4 1542.14
42.9 194.3 1542.94
43.7 194.2 1543.73
44.5 194.1 1544.53
45.3 194 1545.32
B46.1 46.1 193.9 1546.12
46.9 193.8 1546.92
47.7 193.7 1547.72
48.5 193.6 1548.51
49.3 193.5 1549.32
B50.1 50.1 193.4 1550.12
50.9 193.3 1550.92
51.7 193.2 1551.72
52.5 193.1 1552.52
53.3 193 1553.33
B54.1 54.1 192.9 1554.13
54.9 192.8 1554.94
55.7 192.7 1555.75
56.5 192.6 1556.55
57.3 192.5 1557.36
B58.1 58.1 192.4 1558.17
58.9 192.3 1558.98
59.7 192.2 1559.79
60.6 192.1 1560.61
61.4 192 1561.42
1. This channel is unused by the 40-WXC-C
Table 7-39 40-WXC-C Channel Plan (continued)
Band ID Channel Label Frequency (GHz)
Wavelength
(nm)

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
