Cisco ONS 15454 DWDM - Table A-37 MXP_2.5 G_10 E_L Card Trunk Wavelengths; Table A-38 MXP_2.5 G_10 E_L Card Receiver Trunk Side Specifications

A-64
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.9.7 MXP_2.5G_10E_L Card Specifications
• Receiver (trunk side, see Table A-38)
19 189.95 1578.27 59 187.95 1595.06
20 189.9 1578.69 60 187.9 1595.49
21 189.85 1579.10 61 187.85 1595.91
22 189.8 1579.52 62 187.8 1596.34
23 189.75 1579.93 63 187.75 1596.76
24 189.7 1580.35 64 187.7 1597.19
25 189.65 1580.77 65 187.65 1597.62
26 189.6 1581.18 66 187.6 1598.04
27 189.55 1581.60 67 187.55 1598.47
28 189.5 1582.02 68 187.5 1598.89
29 189.45 1582.44 69 187.45 1599.32
30 189.4 1582.85 70 187.4 1599.75
31 189.35 1583.27 71 187.35 1600.17
32 189.3 1583.69 72 187.3 1600.60
33 189.25 1584.11 73 187.25 1601.03
34 189.2 1584.53 74 187.2 1601.46
35 189.15 1584.95 75 187.15 1601.88
36 189.1 1585.36 76 187.1 1602.31
37 189.05 1585.78 77 187.05 1602.74
38 189 1586.20 78 187 1603.17
39 188.95 1586.62 79 186.95 1603.60
40 188.9 1587.04 80 186.9 1604.03
Table A-37 MXP_2.5G_10E_L Card Trunk Wavelengths (continued)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Channel
Number
Frequency
(THz)
Wavelength
(nm)
Table A-38 MXP_2.5G_10E_L Card Receiver Trunk Side Specifications
OSNR
1
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
Chromatic Dispersion
Tolerance
30 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1200 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1000 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 22 dBm —
17 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
15.5 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm —
15 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
