A.9.6 MXP_2.5G_10E_C Card Specifications
• Receiver (trunk side, see Table A-34)
– Receiver: APD
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
• Line (client side)
– Bit rate: 2.5 Gbps per port (OC-48/STM-16)
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode
– Maximum chromatic dispersion allowance: 12 ps/nm (SR SFP version)
– Loopback modes: Terminal and facility
– Connectors: LC (optical)
• Transmitter (client side): Depends on the SFP that is used.
• Receiver (client side): Depends on the SFP that is used.
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.000 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight not including clam shell: 3.1 lb (1.3 kg)
A.9.6 MXP_2.5G_10E_C Card Specifications
The MXP_2.5G_10E_C card has the following specifications:
• Line (trunk side)
– Bit rate: 10.70923 Gbps (in ITU-T G.709 Digital Wrapper/FEC mode)
Table A-34 MXP_2.5G_10E Card Receiver Trunk Side Specifications
OSNR
1
1. OSNR defined with 0.1 nm RBW
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
2. Receiver filter bandwidth greater than or equal to 180 pm (at – 3 dBm)
Chromatic Dispersion
Tolerance
30 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1200 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1000 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 22 dBm —
17 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
15 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm —
15 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
14 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm —
