Chapter 4 Optical Amplifier Cards
4.5.1 OPT-BST-E Faceplate Ports
• Fixed gain mode (with programmable tilt)
• True variable gain
• Gain range of 8 to 23 dBm with the tilt managed at 0 dBm in constant gain mode and output power
mode
• Enhanced gain range of 23 to 26 dBm with unmanaged tilt
• Built-in VOA to control the gain tilt
• Fast transient suppression
• Nondistorting low-frequency transfer function
• Settable maximum output power
• Fixed output power mode (mode used during provisioning)
• ASE compensation in fixed gain mode
• Full monitoring and alarm handling with settable thresholds
• OSRI
• ALS
Note The optical splitters each have a ratio of 1:99. The result is that MON TX and MON RX port power is
about 20 dB lower than COM TX and COM RX port power.
4.5.1 OPT-BST-E Faceplate Ports
The OPT-BST-E amplifier card has eight optical ports located on the faceplate:
• MON RX is the output monitor port (receive section).
• MON TX is the output monitor port.
• COM RX is the input signal port.
• LINE TX is the output signal port.
• LINE RX is the input signal port (receive section).
• COM TX is the output signal port (receive section).
• OSC RX is the OSC add input port.
• OSC TX is the OSC drop output port.
