Chapter 8 Transponder and Muxponder Cards
8.8.15 Onboard Traffic Generation
8.8.15 Onboard Traffic Generation
The MXP_2.5G_10E_C and MXP_2.5G_10E_L cards provide internal traffic generation for testing
purposes according to PRBS, SONET/SDH, or ITU-T G.709.
8.8.16 MXP_2.5G_10E_C and MXP_2.5G_10E_L Card-Level Indicators
Table 8-20 describes the three card-level LEDs on the MXP_2.5G_10E_C and MXP_2.5G_10E_L cards.
8.8.17 MXP_2.5G_10E and MXP_2.5G_10E_L Port-Level Indicators
Table 8-21 describes the port-level LEDs on the MXP_2.5G_10E_C and MXP_2.5G_10E_L cards.
8.9 MXP_MR_2.5G and MXPP_MR_2.5G Cards
The MXP_MR_2.5G card aggregates a mix and match of client Storage Area Network (SAN) service
client inputs (GE, FICON, Fibre Channel, and ESCON) into one 2.5 Gbps STM-16/OC-48 DWDM
signal on the trunk side. It provides one long-reach STM-16/OC-48 port per card and is compliant with
Telcordia GR-253-CORE.
Table 8-20 MXP_2.5G_10E_C and MXP_2.5G_10E_L Card-Level Indicators
Card-Level LED Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready. This LED
is on during reset. The FAIL LED flashes during the boot process. Replace
the card if the red FAIL LED persists.
ACT/STBY LED
Green (Active)
Amber (Standby)
If the ACT/STBY LED is green, the card is operational (one or more ports
active) and ready to carry traffic. If the ACT/STBY LED is amber, the card
is operational and in standby (protect) mode.
Amber SF LED The amber SF LED indicates a signal failure or condition such as LOS, LOF,
or high BERs on one or more of the card’s ports. The amber SF LED is also
on if the transmit and receive fibers are incorrectly connected. If the fibers
are properly connected and the link is working, the light turns off.
Table 8-21 MXP_2.5G_10E_C and MXP_2.5G_10E_L Port-Level Indicators
Port-Level LED Description
Green Client LED
(four LEDs)
A green Client LED indicates that the client port is in service and that it is
receiving a recognized signal. The card has four client ports, and so has four
Client LEDs.
Green DWDM LED The green DWDM LED indicates that the DWDM port is in service and that
it is receiving a recognized signal.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
