17-16
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 17 Performance Monitoring
17.3 DWDM Card Performance Monitoring
The interval is defined in seconds. The maxBaseRate is defined by raw bits per second in one direction
for the Ethernet port (that is, 1 Gbps).
17.2.4.3 Ether Ports History Window
The Ether Port History window lists past Ethernet statistics for the previous time intervals. Depending
on the selected time interval, the History window displays the statistics for each port for the number of
previous time intervals as shown in Table 17-16. The parameters are defined in Table 17-15 on
page 17-14.
17.3 DWDM Card Performance Monitoring
The following sections define PM parameters and definitions for the ONS 15454 OPT-PRE, OPT-BST,
OPT-BST-L, OPT-AMP-L, OPT-AMP-17-C, 32MUX-O, 32DMX-O, 32DMX, 32DMX-L, 40-WSS-C,
40-WSS-CE, 40-WXC-C, 40-DMX-C, 40-DMX-CE, 40-MUX-C, 4MD-xx.x, AD-1C-xx.x,
AD-2C-xx.x, AD-4C-xx.x, AD-1B-xx.x, AD-4B-xx.x, OSCM, OSC-CSM, 32WSS, and
32WSS-LDWDM cards.
17.3.1 Optical Amplifier Card Performance Monitoring Parameters
The PM parameters for the OPT-PRE, OPT-AMP-L, OPT-AMP-17-C, OPT-BST, and OPT-BST-L cards
are listed Table 17-17. For ONS 15454 optics definitions, see the “17.4 Optics and 8b10b PM Parameter
Definitions” section on page 17-20.
17.3.2 Multiplexer and Demultiplexer Card Performance Monitoring
Parameters
The PM parameters for the 32MUX-O, 32WSS, 32WSS-L, 32DMX, 32DMX-L, 32DMX-O, 40-WSS-C,
40-WSS-CE, 40-WXC-C, 40-DMX-C, 40-DMX-CE, and 40-MUX-C cards are listed in Table 17-18.
For ONS 15454 optics definitions, see the “17.4 Optics and 8b10b PM Parameter Definitions” section
on page 17-20.
Table 17-16 Ethernet History Statistics per Time Interval
Time Interval Number of Previous Intervals Displayed
1 minute 60
15 minutes 32
1 hour 24
1 day (24 hours) 7
Table 17-17 Optical PM Parameters for Optical Amplifier Cards
Optical Line Optical Amplifier Line
OPT OPR
