Cisco ONS 15454 DWDM Reference Manual

8-48
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 8 Transponder and Muxponder Cards
8.9.7 Block Diagram
Figure 8-21 MXP_MR_2.5G and MXPP_MR_2.5G Faceplates
For information on safety labels for the cards, see the “8.2.2 Class 1M Laser Product Cards” section on
page 8-6.
8.9.7 Block Diagram
Figure 8-22 shows a block diagram of the MXP_MR_2.5G card. The card has eight SFP client interfaces.
Ports 1 and 2 can be used for GE, FC, FICON, or ESCON. Ports 3 through 8 are used for ESCON client
interfaces. There are two SERDES blocks dedicated to the high-speed interfaces (GE, FC, FICON, and
ESCON) and two SERDES blocks for the ESCON interfaces. A FPGA is provided to support different
configurations for different modes of operation. This FPGA has a Universal Test and Operations
MXP_MR_2.5G MXPP_MR_2.5G
124077
MXP
MR
2.5G
15xx.xx
15xx.xx
FAIL
ACT/STBY
SF
MXPP
MR
2.5G
15xx.xx
15xx.xx
RX TXRX TXRX TXRX TXRX TXRX TXRX TXRX TX
DWDMADWDMB
FAIL
ACT/STBY
SF
RX TX RX TX
RX TXRX TXRX TXRX TXRX TXRX TXRX TXRX TX
DWDM
RX TX
