Cisco ONS 15454 DWDM Reference Manual

9-34
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 9 Node Reference
9.4.1 Line Termination Mesh Node
Figure 9-25 Line Termination Mesh Nodes—ROADM With MMU Cards
159336
ADD
OPT-PRE
OPT-BST
Line
DCMOSCM
xxWSS
MMU
70/30
xxDMX
DROP
xxDMX
DROP
40-DMX-C
DROP
40-DMX-C
DROP
40-MUX-C
ADD
40-MUX-C
ADD
ADD
OPT-BST
Line
DCN
Extension
OSCM
TCC
TCC
OPT-PRE
DCM
xxWSS
MMU
70/30
OPT-PRE
OPT-BST
Line
DCMOSCM
OPT-BST
Line
OSCM
OPT-PRE
DCM
40-WXC-C
Node A
Node B
40-WXC-C
40-WXC-C
AMP-17-C
PP-MESH-4
AMP-17-C
70/30
40-WXC-C
70/30

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
