Appendix A Hardware Specifications
A.2.2 Temperature
A.2.2 Temperature
• Operating temperature:
– Long term: 0 to 40 degrees Celsius (32 to 104 degrees Fahrenheit)
– Short term: Functionality is guaranteed at -5 to 55 degrees Celsius (23 to 131 degrees
Fahrenheit), according to GR-63 Issue 3
The indicated temperatures are the ambient ones in which the shelf can be placed.
A.3 Common Control Card Specifications
This section provides specifications for the TCC2, TCC2P, AIC, and AIC-I cards, the alarm expansion
panel (AEP), the MIC-A/P and MIC-C/T/P FMECs, and the MS-ISC-100T card.
For compliance information, refer to the Cisco Optical Transport Products Safety and Compliance
Information document.
Optical
Add/Drop Cards
AD-1C-xx.x 17 0.35 58.0
AD-2C-xx.x 17 0.35 58.0
AD-4C-xx.x 17 0.35 58.0
AD-1B-xx.x 17 0.35 58.0
AD-4B-xx.x 17 0.35 58.0
Transponder
and Muxponder
Cards
TXP_MR_10G 35 0.73 120
TXP_MR_10E 50 1.05 171
TXP_MR_10E_C 50 1.05 171
TXP_MR_10E_L 50 1.05 171
TXP_MR_2.5G 35 0.73 120
TXPP_MR_2.5G 50 1.05 171
MXP_2.5G_10G 50 1.05 171
MXP_2.5G_10E 50 1.05 171
MXP_2.5G_10E_C 50 1.05 171
MXP_2.5G_10E_L 50 1.05 171
MXP_MR_2.5G 50 1.05 171
MXPP_MR_2.5G 50 1.05 171
Transponder
and Muxponder
Cards
MXP_MR_10DME_C 60 1.25 205
MXP_MR_10DME_L 60 1.25 205
ADM-10G 135 2.81 461
Table A-2 Individual Card Power Requirements (continued)(Typical Values at 25 degrees C)
Card Type Card Name (Power in Watts) Amperes at –48 V BTU/Hr.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
