Chapter 6 Optical Add/Drop Cards
6.5.2 Power Monitoring
6.5.2 Power Monitoring
Physical photodiodes P1 through P10 and virtual photodiodes V1 and V2 monitor the power for the
AD-4C-xx.x card. The returned power level values are calibrated to the ports as shown in Table 6-13.
For information on the associated TL1 AIDs for the optical power monitoring points, refer the “CTC
Port Numbers and TL1 Aids” section in Cisco ONS SONET TL1 Command Guide, Release 8.5.
6.5.3 AD-4C-xx.x Card-Level Indicators
The AD-4C-xx.x card has three card-level LED indicators, described in Table 6-14.
Table 6-12 AD-4C-xx.x Channel Sets
Band ID Add/Drop Wavelengths
Band 30.3 (A) 1530.3, 1531.2, 1531.9, 1532.6
Band 34.2 (B) 1534.2, 1535.0, 1535.8, 1536.6
Band 38.1 (C) 1538.1, 1538.9, 1539.7, 1540.5
Band 42.1 (D) 1542.1, 1542.9, 1543.7, 1544.5
Band 46.1 (E) 1546.1, 1546.9, 1547.7, 1548.5
Band 50.1 (F) 1550.1, 1550.9, 1551.7, 1552.5
Band 54.1 (G) 1554.1, 1554.9, 1555.7, 1556.5
Band 58.1 (H) 1558.1, 1558.9, 1559.7, 1560.6
Table 6-13 AD-4C-xx.x Port Calibration
Photodiode CTC Type Name Calibrated to Port
P1–P4 ADD COM TX
P5–P8 DROP DROP TX
P9 IN EXP EXP RX
P10 OUT EXP EXP TX
V1 IN COM COM RX
V2 OUT COM COM TX
Table 6-14 AD-4C-xx.x Card-Level Indicators
Card-Level Indicators Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready or that
there is an internal hardware failure. Replace the card if the red FAIL LED
persists.
