Cisco ONS 15454 DWDM Reference Manual

7-17
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.3.6 32WSS Card-Level Indicators
7.3.6 32WSS Card-Level Indicators
Table 7-10 describes the three card-level LED indicators on the 32WSS card.
B34.2 34.2 195.4 1534.25
35.0 195.3 1535.04
35.8 195.2 1535.82
36.1 195.1 1536.61
B38.1 38.1 194.9 1538.19
38.9 194.8 1538.87
39.7 194.7 1539.77
40.5 194.6 1540.46
B42.1 42.1 194.4 1542.14
42.9 194.3 1542.94
43.7 194.2 1543.73
44.5 194.1 1544.53
B46.1 46.1 193.9 1546.12
46.9 193.8 1546.92
47.7 193.7 1547.72
48.5 193.6 1548.51
B50.1 50.1 193.4 1550.12
50.9 193.3 1550.92
51.7 193.2 1551.72
52.5 193.1 1552.52
B54.1 54.1 192.9 1554.13
54.9 192.8 1554.94
55.7 192.7 1555.75
56.5 192.6 1556.55
B58.1 58.1 192.4 1558.17
58.9 192.3 1558.98
59.7 192.2 1559.79
60.6 192.1 1560.61
Table 7-9 32WSS Channel Allocation Plan (continued)
Band ID Channel Label Frequency (THz) Wavelength (nm)

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
