Cisco ONS 15454 DWDM Reference Manual

7-62
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.11.6 40-WSS-CE Card-Level Indicators
7.11.6 40-WSS-CE Card-Level Indicators
The 40-WSS-CE card has three card-level LED indicators, described in Table 7-36.
B42.5 42.5 194.35 1542.54
43.3 194.25 1543.33
44.1 194.15 1544.13
44.9 194.05 1544.92
45.7 193.95 1545.72
B46.5 46.5 193.85 1546.52
47.3 193.75 1547.32
48.1 193.65 1548.11
48.9 193.55 1548.91
49.7 193.45 1549.72
B50.5 50.5 193.35 1550.52
51.3 193.25 1551.32
52.1 193.15 1552.12
52.9 193.05 1552.93
53.7 192.95 1553.73
B54.4 54.4 192.85 1554.54
55.3 192.75 1555.34
56.1 192.65 1556.15
56.9 192.55 1556.96
57.8 192.45 1557.77
B58.6 58.6 192.35 1558.58
59.4 192.25 1559.39
60.2 192.15 1560.20
61.0 192.05 1561.01
61.8 191.95 1561.83
Table 7-35 40-WSS-CE Channel Plan (continued)
Band ID Channel Label Frequency (GHz) Wavelength (nm)
Table 7-36 40-WSS-CE Card-Level Indicators
Card-Level Indicators Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready or that an
internal hardware failure occurred. Replace the card if the red FAIL LED
persists.

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
