Chapter 4 Optical Amplifier Cards
4.7.3 OPT-AMP-L Power Monitoring
4.7.3 OPT-AMP-L Power Monitoring
Physical photodiodes P1 through P7 monitor the power for the OPT-AMP-L card. Table 4-11 shows the
returned power level values calibrated to each port.
For information on the associated TL1 AIDs for the optical power monitoring points, refer the “CTC
Port Numbers and TL1 Aids” section in Cisco ONS SONET TL1 Command Guide, Release 8.5.
4.7.4 OPT-AMP-L Card-Level Indicators
Table 4-12 shows the three card-level LEDs on the OPT-AMP-L card.
4.7.5 OPT-AMP-L Port-Level Indicators
You can determine the status of the card ports using the LCD screen on the ONS 15454 fan-tray
assembly. Use the LCD to view the status of any port or card slot; the screen displays the number and
severity of alarms for a given port or slot.
Table 4-11 OPT-AMP-L Port Calibration
Photodiode CTC Type Name Calibrated to Port
P1 Input COM Power COM RX
P2 Output DC (total power) DC TX
Output DC (signal power)
P3 Input DC (input power) DC RX
P4 Output Line Transmit (total power) LINE TX
Output Line Transmit (signal power)
P5 Input Line Receive Power LINE RX
P6 Output OSC Receive Power OSC RX
P7 Input OSC Transmit Power
Table 4-12 OPT-AMP-L Card-Level Indicators
Card-Level Indicators Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready or that an
internal hardware failure occurred. Replace the card if the red FAIL LED
persists.
Green ACT LED The green ACT LED indicates that the OPT-AMP-L is carrying traffic or is
traffic-ready.
Amber SF LED The amber SF LED indicates a signal failure or condition such as LOS on
one or more of the card’s ports. The amber SF LED also turns on when the
transmit and receive fibers are incorrectly connected. When the fibers are
properly connected, the light turns off.
