Cisco ONS 15454 DWDM Reference Manual

A-65
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.9.8 MXP_MR_10DME_C Card Specifications
– Receiver: APD
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
– Receiver input wavelength range: 1570 to 1604 nm
• Line (client side)
– Bit rate: 2.5 Gbps per port (OC-48/STM-16)
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode
– Maximum chromatic dispersion allowance: 12 ps/nm (SR SFP version)
– Loopback modes: Terminal and facility
– Connectors: LC (optical)
• Transmitter (client side): Depends on the SFP that is used.
• Receiver (client side): Depends on the SFP that is used.
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.000 in. (228.6 mm)
– Depth with backplane connector: 9.250 in. (235 mm)
– Weight not including clam shell: 3.1 lb (1.3 kg)
A.9.8 MXP_MR_10DME_C Card Specifications
The MXP_MR_10DME_C card has the following specifications:
• Payload configuration
– FC1G—Fibre Channel 1.06 Gbps
– FC2G—Fibre Channel 2.125 Gbps
– FC4G—Fibre Channel 4.25 Gbps
– FICON1G—Fiber connectivity 1.06 Gbps (IBM signal)
– FICON2G—Fiber connectivity 2.125 Gbps (IBM signal)
– FICON4G—Fiber connectivity 4.25 Gbps (IBM signal)
– ISC compatability
– ISC peer 1G
13 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm —
1. OSNR defined with 0.1 nm RBW
2. Receiver filter bandwidth greater than or equal to 180 pm (at – 3 dBm)
Table A-38 MXP_2.5G_10E_L Card Receiver Trunk Side Specifications (continued)
OSNR
1
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
Chromatic Dispersion
Tolerance

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
