Cisco ONS 15454 DWDM Reference Manual

9-33
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 9 Node Reference
9.4.1 Line Termination Mesh Node
Figure 9-24 Line Termination Mesh Node Side—40-WSS-C Cards
Figure 9-25 shows a functional block diagram of a node that interconnects a ROADM with MMU cards
with two native line termination mesh sides.
40-WXC-C
40-DMX-C
Drop
Add
OPT-PRE
AMP-BST
159333
DCMOSCM
40-WSS-C
70/30
70/30
to/from
PP-MESH-4
or PP-MESH-8

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
