Chapter 1 Shelf Assembly Hardware
1.6 Front Door
Figure 1-22 shows how to remove the ONS 15454 ETSI front door.
Figure 1-22 Removing the ONS 15454 ETSI Front Door
An erasable label is pasted on the inside of the front door. You can use the label to record slot
assignments, port assignments, card types, node ID, rack ID, and serial number for the ONS 15454.
61237
FAN FA IL
CRIT
MAJ
MIN
Door hinge
Assembly hinge pin
Assembly hinge
Translucent
circles
for LED
viewing
