12-13
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 12 Cisco Transport Controller Operation
12.5.2 Node View (Multishelf Mode), Node View (Single-Shelf Mode), and Shelf View (Multishelf Mode)
Figure 12-6 Facility Loopback Indicator
12.5.2.2 Multishelf View Card Shortcuts
If you move your mouse over cards in the multishelf view graphic, popups display additional information
about the card including the card type; the card status (active or standby); the type of alarm, such as
Critical, Major, or Minor (if any); the alarm profile used by the card; and for transponder (TXP) or
muxponder (MXP) cards, the wavelength of the dense wavelength division multiplexing (DWDM) port.
12.5.2.3 Node View (Single-Shelf Mode) or Shelf View (Multishelf Mode) Card Shortcuts
If you move your mouse over cards in the node view (single-shelf mode) or shelf view (multishelf mode)
graphic, popups display additional information about the card including the card type; the card status
(active or standby); the type of alarm, such as Critical, Major, or Minor (if any); the alarm profile used
by the card; and for TXP or MXP cards, the wavelength of the DWDM port. Right-click a card to reveal
a shortcut menu, which you can use to open, reset, delete, or change a card. Right-click a slot to
preprovision a card (that is, provision a slot before installing the card).
12.5.2.4 Multishelf View Tabs
Table 12-8 lists the tabs and subtabs available in the multishelf view. The actions on these tabs apply to
the multishelf node and its subtending shelves.
Table 12-8 Multishelf View Tabs and Subtabs
Tab Description Subtabs
Alarms Lists current alarms (CR, MJ, MN) for the
multishelf node and updates them in real time.
—
Conditions Displays a list of standing conditions on the
multishelf node.
—
History Provides a history of multishelf node alarms
including the date, type, and severity of each
alarm. The Session subtab displays alarms and
events for the current session. The Node subtab
displays alarms and events retrieved from a
fixed-size log on the node.
Session, Node
Circuits Creates, deletes, edits, and maps circuits. Circuits, Rolls
Provisioning Provisions the ONS 15454 multishelf node. General, Network, OSI, Security,
SNMP, Comm Channels, Alarm
Profiles, Defaults, WDM-ANS
