Chapter 6 Optical Add/Drop Cards
6.3 AD-1C-xx.x Card
Figure 6-6 AD-1C-xx.x Faceplate
For information on safety labels for the card, see the “6.2 Class 1M Laser Product Safety Lasers”
section on page 6-7.
Figure 6-7 shows a block diagram of the AD-1C-xx.x card.
AD-1C
-X.XX
FAIL
ACT
SF
RX
15xx.xx
TX
RX
EXP
TX
RX
COM
TX
