A-48
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.9 Transponder and Muxponder Card Specifications
The AD-4B-xx.x card optical input and output power varies with amplifier output levels and the class of
transponder interfaces used. See Table 6-3 on page 6-3 through Table 6-6 on page 6-5 for this
information.
The AD-4B-xx.x has the following additional specifications:
• Dimensions
–
Height: 12.650 in. (321.3 mm)
–
Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
–
Depth: 9.0 in. (228.6 mm)
A.9 Transponder and Muxponder Card Specifications
This section provides specifications for the TXP_MR_10G, MXP_2.5G_10G, TXP_MR_2.5G,
TXPP_MR_2.5G, MXP_MR_2.5G, MXPP_MR_2.5G, MXP_2.5G_10E, MXP_2.5G_10E_C,
MXP_2.5G_10E, TXP_MR_10E, TXP_MR_10E_C, TXP_MR_10E_L, MXP_MR_10DME_C,
MXP_MR_10DME_L cards, and ADM-10G cards.
For compliance information, refer to the Cisco Optical Transport Products Safety and Compliance
Information document.
A.9.1 TXP_MR_10G Card Specifications
The TXP_MR_10G card has the following specifications:
• Line (trunk side)
–
Bit rate:
9.95328 Gbps for OC-192/STM-64
10.70923 Gbps with ITU-T G.709 Digital Wrapper/forward error correction (FEC)
10.3125 Gbps for 10 Gigabit Ethernet (GE)
11.095 Gbps with ITU-T G.709 Digital Wrapper/FEC over 10 GE
–
Code: Scrambled NRZ
–
Fiber: 1550-nm single-mode
–
Maximum chromatic dispersion allowance: 1000 ps/nm
–
Loopback modes: Terminal and facility
B46.1 Wavelengths 1545.245 or lower Wavelengths 1549.695 or higher
B50.1 Wavelengths 1549.235 or lower Wavelengths 1553.705 or higher
B54.1 Wavelengths 1553.255 or lower Wavelengths 1557.745 or higher
B58.1 Wavelengths 1557.285 or lower —
Table A-31 AD-4B-xx.x Transmit and Receive Dropped Band Wavelength Ranges (continued)
Tx (Dropped) Band
Rx (Express) Band
Left Side (nm) Right Side (nm)
