Cisco ONS 15454 DWDM Reference Manual

A-30
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.7 40-DMX-CE Card Specifications
The 40-DMX-C card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.7.7 40-DMX-CE Card Specifications
The 40-DMX-CE card optical specifications are listed in Table A-16.
Note For power specifications, see Table A-2 on page A-6.
Table A-15 40-DMX-C Card Optical Specifications
Parameter Note Condition Min Max Unit
Receive (Rx) filter
shape
All SOP and within
whole operating
temperature range
–1 dB bandwidth,
COM RX => TX 1,
40 (OUT)
+/–100 — pm
–3 dB bandwidth,
COM RX => TX 1,
40 (OUT)
+/–199 — pm
Insertion loss All SOP and within
whole operating
temperature range
COM RX => TX 1,
40
—5.8dB
VOA dynamic range — COM RX => TX 1,
40
25 — dB
Maximum optical
input power
— — 300 — mW
Table A-16 40-DMX-CE Card Optical Specifications
Parameter Note Condition Min Max Unit
Receive (Rx) filter
shape
All SOP and within
whole operating
temperature range
–1 dB bandwidth,
COM RX => TX 1,
40 (OUT)
+/–100 — pm
–3 dB bandwidth,
COM RX => TX 1,
40 (OUT)
+/–199 — pm
Insertion loss All SOP and within
whole operating
temperature range
COM RX => TX 1,
40
—5.8dB

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
