Cisco ONS 15454 DWDM - Figure 7-35 MMU Faceplate and Ports; MMU Block Diagram

7-70
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.13.2 MMU Block Diagram
Figure 7-35 MMU Faceplate and Ports
7.13.2 MMU Block Diagram
Figure 7-36 provides a high-level functional block diagram of the MMU card.
145190
ACT
FAIL
MMU
SF
RX TX
EXP A
RX
TX
EXP
RX
TX
COM
