Appendix A Hardware Specifications
A.9.10 TXP_MR_10E Card Specifications
– 1542.14 to 1544.92 nm (four channels)
– 1546.12 to 1548.92 nm (four channels)
– 1550.12 to 1552.93 nm (four channels)
– 1554.13 to 1556.96 nm (four channels)
– 1558.17 to 1561.01 nm (four channels)
L-band frequency plan (five card versions, each with eight tunable channels on the ITU 50-GHz
grid):
– 1577.44 to 1580.35 nm (eight channels)
– 1580.77 to 1583.69 nm (eight channels)
– 1584.11 to 1587.04 nm (eight channels)
– 1587.46 to 1590.41 nm (eight channels)
– 1590.83 to 1593.79 nm (eight channels)
• Receiver (trunk side, see Table A-41)
– Receiver: APD
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
• Line (client side):
– 10-Gigabit Small Form-factor Pluggable (XFP)-based SR
– Bit rate: 10GE (10.3125 Gbps), 10G FC (10.51875 Gbps), or STM-64/OC-192
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode
– Maximum chromatic dispersion allowance: 6.6 ps/nm
– Loopback modes: Terminal and facility
– Connectors: LC
– Compliance: Telcordia GR-253-CORE, ITU-T G.707, ITU-T G.957, ITU-T G.691
Table A-41 TXP_MR_10E Card Receiver Trunk Side Specifications
OSNR
1
1. OSNR defined with 0.1 nm RBW
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
2. Receiver filter bandwidth greater than or equal to 180 pm (at – 3 dBm)
Chromatic Dispersion
Tolerance
30 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm +/– 1200 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 20 dBm + – 1000 ps/nm
26 dB Off < 10 exp – 12 N/A – 8 to – 22 dBm —
17 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
15 dB Standard < 10 exp – 5 < 10 exp – 15 – 8 to – 18 dBm —
15 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm +/– 800 ps/nm
14 dB Enhanced < 7 x 10 exp – 4 < 10 exp – 15 – 8 to – 18 dBm —
