Chapter 7 Reconfigurable Optical Add/Drop Cards
7.9.4 40-MUX-C Card Channel Plan
7.9.4 40-MUX-C Card Channel Plan
Table 7-27 shows the 40 ITU-T 100-GHz-spaced, C band channels (wavelengths) that are multiplexed
by the 40-MUX-C card.
Table 7-26 40-MUX-C Port Calibration
Photodiode CTC Type Name Calibrated to Port
P1–P40 ADD ADD RX
P41 OUTPUT COM COM-TX
Table 7-27 40-MUX-C Channel Plan
Band ID Channel Label Frequency (GHz)
Wavelength
(nm)
B30.3 30.3 195.9 1530.33
31.1 195.8 1531.12
31.9 195.7 1531.90
32.6 195.6 1532.68
33.4 195.5 1533.47
B34.2 34.2 195.4 1534.25
35.0 195.3 1535.04
35.8 195.2 1535.82
36.6 195.1 1536.61
37.4 195 1537.40
B38.1 38.1 194.9 1538.19
38.9 194.8 1538.98
39.7 194.7 1539.77
40.5 194.6 1540.56
41.3 194.5 1541.35
B42.1 42.1 194.4 1542.14
42.9 194.3 1542.94
43.7 194.2 1543.73
44.5 194.1 1544.53
45.3 194 1545.32
B46.1 46.1 193.9 1546.12
46.9 193.8 1546.92
47.7 193.7 1547.72
48.5 193.6 1548.51
49.3 193.5 1549.32

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
