Cisco ONS 15454 DWDM - A.7.9 40-WSS-CE Card Specifications

A-33
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.9 40-WSS-CE Card Specifications
The 40-WSS-C card has the following additional specifications:
• Dimensions
– Height: 8.66 in. (220 mm)
– Width: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
– Depth: 1.42 in. (36 mm)
A.7.9 40-WSS-CE Card Specifications
The 40-WSS-CE card optical specifications are listed in Table A-19.
B42.1 42.1 194.4 1542.14
42.9 194.3 1542.94
43.7 194.2 1543.73
44.5 194.1 1544.53
45.3 194.0 1545.32
B46.1 46.1 193.9 1546.12
46.9 193.8 1546.92
47.7 193.7 1547.72
48.5 193.6 1548.51
49.3 193.5 1549.32
B50.1 50.1 193.4 1550.12
50.9 193.3 1550.92
51.7 193.2 1551.72
52.5 193.1 1552.52
53.3 193.0 1553.33
54.1 54.1 192.9 1544.13
54.9 192.8 1544.94
55.7 192.7 1555.75
56.5 192.6 1556.55
57.3 192.5 1557.36
B58.1 58.1 192.4 1558.17
58.9 192.3 1558.98
59.7 192.2 1559.79
60.6 192.1 1560.61
61.4 192.0 1561.42
Table A-18 40-WSS-C Channel Grid (continued)
Band ID Channel Label Frequency (THz) Wavelength (nm)
