Appendix A Hardware Specifications
A.9.14 GE_XP and 10GE_XP Card Specifications
• Transmitter (trunk side)
– Maximum transmitter output power: +3 dBm
– Minimum transmitter output power: -1 dBm
– Transmitter: EML laser
– Wavelength stability (drift): +/– 100 picometers (pm)
Note An optical device on the card keeps the laser wavelength locked as closely as possible to the ITU nominal
value. The allowed drift is +/– 25 pm.
• Currently available wavelengths and versions of GE_XP and 10GE_XP: C Band, 100 GHz spacing.
• Receiver (trunk side, see Table A-46)
– Receiver: APD
– Link loss budget: 24 dB minimum, with no dispersion or 22 dB optical path loss at
BER = 1 * 10 exp – 12 including dispersion
• Line (client side)
– Bit rate: 1.125Gbps (GE) or 10.3125Gbps (10GE)
– Code: Scrambled NRZ
– Fiber: 1310-nm single-mode or 850-nm multimode
– Maximum chromatic dispersion allowance: 12 ps/nm (SR SFP version)
– Loopback modes: Terminal and facility
– Connectors: LC (optical)
• Transmitter (client side): Depends on the SFP that is used.
• Receiver (client side): Depends on the SFP that is used.
Table A-46 GE_XP Card Receiver Trunk Side Specifications
OSNR
1
1. OSNR defined with 0.1 nm RBW
FEC Type Pre-FEC BER Post-FEC BER
Input Power
Sensitivity
2
2. Receiver filter bandwidth greater than or equal to 180 pm (at – 3 dBm)
Chromatic Dispersion
Tolerance
30 dB Off 1.00E – 12 N/A – 7 to – 23 dBm —
30 dB Off 1.00E – 12 N/A – 7 to – 20 dBm – 500 to 1600 ps/nm
24 dB Off 1.00E – 12 N/A – 7 to – 18 dBm —
27 dB Off 1.00E – 12 N/A – 7 to – 18 dBm – 500 to 1600 ps/nm
18 dB Standard 1.00E – 05 1.00E – 15 – 7 to – 18 dBm —
19 dB Standard 1.00E – 05 1.00E – 15 – 7 to – 18 dBm – 500 to 1600 ps/nm
30 dB Enhanced 1.00E – 04 1.00E – 15 – 7 to – 27 dBm —
30 dB Enhanced 1.00E – 04 1.00E – 15 – 7 to – 24 dBm – 500 to 1600 ps/nm
15 dB Enhanced 1.00E – 04 1.00E – 15 – 7 to – 18 dBm —
15 dB Enhanced 1.00E – 04 1.00E – 15 – 7 to – 18 dBm – 500 to 1600 ps/nm

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
