Appendix A Hardware Specifications
A.6 Multiplexer and Demultiplexer Cards
A.6 Multiplexer and Demultiplexer Cards
This section provides specifications for the 32MUX-O, 32DMX-O, and 4MD-xx.x cards.
A.6.1 32MUX-O Card Specifications
The 32MUX-O card optical specifications are listed in Table A-3.
Note For power specifications, see Table A-2 on page A-6.
The 32MUX-O card has the following additional specifications:
• Dimensions
– Height: 12.65 in. (321.3 mm)
– Width: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.6.2 32DMX-O Card Specifications
The 32DMX-O card optical specifications are listed in Table A-4.
Note For power specifications, see Table A-2 on page A-6.
Table A-3 32MUX-O Optical Specifications
Parameter Note Condition Min Max Unit
Transmit (Tx) filter
shape (–1 dB
bandwidth)
All standard operating
procedures (SOP) and
within whole operating
temperature range
In 1/32—Out beginning
of life (BOL)
+/–180 +/–300 pm
In 1/32—Out end of life
(EOL)
+/–160 +/–300 pm
Insertion loss All SOP and within
whole operating
temperature range
In 1/32—Out BOL 4 8.0 dB
In 1/32—Out EOL 4 8.5 dB
VOA dynamic range — — 25 — dB
Optical monitor
tap-splitting ratio on
monitor port
Optical monitor port
with respect to output
port in multiplexer
only
—1921dB
Maximum optical
input power
— — 300 — mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
