• Mask (255.255.255.255) is a 32-bit mask, meaning only the 172.20.214.94 address is a destination.
• Gateway (172.20.214.93) indicates that the destination host is accessed through a node with IP
address 172.20.214.93.
• Interface (pdcc0) indicates that a DCC interface is used to reach the gateway.
15.6 External Firewalls
This section provides sample access control lists for external firewalls. Table 15-10 lists the ports that
are used by the TCC2/TCC2P.
Table 15-10 Ports Used by the TCC2/TCC2P
Port Function Action
1
1. D = deny, NA = not applicable, OK = do not deny
0 Never used D
20 FTP D
21 FTP control D
22 SSH D
23 Telnet D
80 HTTP D
111 SUNRPC NA
161 SNMP traps destinations D
162 SNMP traps destinations D
513 rlogin D
683 CORBA IIOP OK
1080 Proxy server (socks) D
2001-2017 I/O card Telnet D
2018 DCC processor on active TCC2/TCC2P D
2361 TL1 D
3082 Raw TL1 D
3083 TL1 D
5001 BLSR server port D
5002 BLSR client port D
7200 SNMP alarm input port D
9100 EQM port D
9401 TCC boot port D
9999 Flash manager D
10240-12287 Proxy client D
57790 Default TCC listener port OK

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
