Cisco ONS 15454 DWDM Reference Manual

11-11
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 11 Optical Channel Circuits and Virtual Patchcords Reference
11.2 Virtual Patchcords
Table 11-4 shows the PPC OCH trunk, OCH filter, and OTS ports.
Table 11-4 Provisionable Patchcord Ports
Card OCH Trunk Port OTS Port OCH Filter Port
TXPs
MXPs
GE_XP
10GE_XP
ADM-10G
ITU-T line cards
Any trunk port — —
OPT-BST
OPT-BST-E
OPT-BST-L
—COM RX
1
LINE RX
LINE TX
—
OPT-AMP-17-C
OPT-AMP-L
—COM RX
2
COM TX
3
LINE RX
3
LINE TX
3
—
OPT-PRE — COM RX
4
COM TX
4
—
OSC-CSM — COM RX
1
LINE RX
LINE TX
—
32MUX
32MUX-O
40-MUX-C
— — Any CHAN RX port
32DMX
32DMX-L
32DMX-O
40-DMX-C
40-DMX-CE
——Any CHAN TX port
32WSS
32WSS-L
40-WSS-C
40-WSS-CE
— — Any ADD port
40-WXC-C — COM RX
COM TX
—

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
