Chapter 7 Reconfigurable Optical Add/Drop Cards
7.8.6 40-DMX-CE Card-Level Indicators
7.8.6 40-DMX-CE Card-Level Indicators
The 40-DMX-CE card has three card-level LED indicators, described in Table 7-25.
B42.5 42.5 194.35 1542.54
43.3 194.25 1543.33
44.1 194.15 1544.13
44.9 194.05 1544.92
45.7 193.95 1545.72
B46.5 46.5 193.85 1546.52
47.3 193.75 1547.32
48.1 193.65 1548.11
48.9 193.55 1548.91
49.7 193.45 1549.72
B50.5 50.5 193.35 1550.52
51.3 193.25 1551.32
52.1 193.15 1552.12
52.9 193.05 1552.93
53.7 192.95 1553.73
B54.4 54.4 192.85 1554.54
55.3 192.75 1555.34
56.1 192.65 1556.15
56.9 192.55 1556.96
57.8 192.45 1557.77
B58.6 58.6 192.35 1558.58
59.4 192.25 1559.39
60.2 192.15 1560.20
61.0 192.05 1561.01
61.8 191.95 1561.83
Table 7-24 40-DMX-CE Card Channel Plan (continued)
Band ID Channel Label Frequency (GHz) Wavelength (nm)
Table 7-25 40-DMX-CE Card-Level Indicators
Card-Level Indicators Description
Red FAIL LED The red FAIL LED indicates that the card’s processor is not ready or that an
internal hardware failure occurred. Replace the card if the red FAIL LED
persists.
