A.8.2 AD-2C-xx.x Card Specifications
The AD-1C-xx.x card optical input and output power varies with amplifier output levels and the class of
transponder interfaces used. See Table 6-3 on page 6-3 through Table 6-6 on page 6-5 for this
information.
The AD-1C-xx.x card has the following additional specifications:
• Dimensions
– Height: 12.650 in. (321.3 mm)
– Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.0 in. (228.6 mm)
A.8.2 AD-2C-xx.x Card Specifications
Table A-24 lists the AD-2C-xx.x optical specifications.
Insertion loss
(add section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
xx.xx Rx—COM Tx — 2.6 dB
VOA dynamic range — — 30 — dB
Maximum optical
input power
— — 300 — mW
Table A-23 AD-1C-xx.x Card Optical Specifications (continued)
Parameter Note Condition Min Max Unit
Table A-24 AD-2C-xx.x Card Optical Specifications
Parameter Note Condition Min Max Unit
Trx filter shape
(–0.5 dB bandwidth)
TrxBW
2
All SOP and within whole
operating temperature range
COM Rx—xx.xx Tx
COM Rx—yy.yy Tx
+/–180 — pm
xx.xx Rx—COM Tx
yy.yy Rx—COM Tx
+/–180 —
Rfx filter shape
(–0.5 dB bandwidth)
RfxBW
2
All SOP and within whole
operating temperature range
COM Rx—Exp Tx
Exp Rx—COM Tx
+/–180 — pm
Insertion loss
(drop section)
All SOP and within whole
operating temperature range
(two connectors included)
COM Rx—xx.xx Tx — 2.0 dB
COM Rx—yy.yy Tx — 2.4 dB
Insertion loss
(express section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
COM Rx—Exp Tx — 2.7 dB
Exp Rx—COM Tx — 1.6 dB
Insertion loss
(add section)
VOA at minimum attenuation;
all SOP and within whole
operating temperature range
(two connectors included)
xx.xx Rx—COM Tx — 3.1 dB
yy.yy Rx—COM Tx — 2.7 dB
