Cisco ONS 15454 DWDM Reference Manual

B-4
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix B Administrative and Service States
B.3.2 DWDM Card Service State Transitions
B.3.2 DWDM Card Service State Transitions
Table B-5 lists ANSI and ETSI service state transitions for AD-1B-xx.x, AD-4B-xx.x, AD-1C-xx.x,
AD-2C-xx.x, AD-4C-xx.x, OSC-CSM, OSCM, OPT-BST, OPT-BST-E, OPT-BST-L, OPT-AMP-L,
OPT-PRE, OPT-AMP-17-C, OPT-AMP-17-C, 4MD-xx.x, 32WSS, 32WSS-L, 32MUX-O, 32DMX,
32DMX-L, 32DMX-O, 40-MUX-C, 40-DMX-C, 40-DMX-CE, 40-WSS-C, 40-WSS-CE, and
40-WXC-C cards.
OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Connect a shelf. IS-NR (ANSI)
Unlocked-enabled (ETSI)
Connect an invalid
shelf.
OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Delete a shelf. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled (ETSI)
OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
Connect a shelf. IS-NR (ANSI)
Unlocked-enabled (ETSI)
Connect an invalid
shelf.
OOS-AU,MEA (ANSI)
Unlocked-disabled,mismatchOfEquipment (ETSI)
Delete a shelf. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled (ETSI)
IS-NR (ANSI)
Unlocked-enabled (ETSI)
Delete a shelf. OOS-AUMA,UAS (ANSI)
Locked-disabled,unassigned (ETSI)
Disconnect a shelf. OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
OOS-AUMA,MEA & UAS (ANSI)
Locked-disabled,mismatchOfEquipment &
unassigned (ETSI)
Disconnect a shelf. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled (ETSI)
OOS-AUMA,AINS & MEA (ANSI)
Locked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Disconnect a shelf. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
OOS-AU,MEA (ANSI)
Unlocked-disabled,mismatchOfEquipment
(ETSI)
Disconnect a shelf. OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
Delete a shelf. OOS-AUMA,MEA & UAS (ANSI)
Locked-disabled,mismatchOfEquipment &
unassigned (ETSI)
Table B-4 ONS 15454 Shelf Service State Transitions (continued)
Current Service State Action Next Service State

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
