Cisco ONS 15454 DWDM Reference Manual

B-5
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix B Administrative and Service States
B.3.2 DWDM Card Service State Transitions
Table B-5 ONS 15454 Optical Unit Service State Transitions
Current Service State Action Next Service State
IS-NR (ANSI)
Unlocked-enabled (ETSI)
Delete the card. OOS-AUMA,UAS (ANSI)
Locked-disabled,unassigned (ETSI)
Pull the card. OOS-AU,UEQ (ANSI)
Unlocked-disabled,notInstalled (ETSI)
Reset the card. OOS-AU,SWDL (ANSI)
Unlocked-disabled,softwareDownload (ETSI)
Alarm/condition is
raised.
OOS-AU,FLT (ANSI)
Unlocked-disabled,failed (ETSI)
OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Pull the card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Delete the card. If the card is valid:
• OOS-AUMA,UAS (ANSI)
• Locked-disabled,unassigned (ETSI)
If the card is invalid:
• OOS-AUMA,MEA & UAS (ANSI)
• Locked-disabled,mismatchOfEquipment &
unassigned (ETSI)
OOS-AU,AINS & SWDL (ANSI)
Unlocked-disabled,automaticInService &
softwareDownload (ETSI)
Restart completed. IS-NR (ANSI)
Unlocked-enabled (ETSI)
OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Pull the card. OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
OOS-AU,AINS & UEQ (ANSI)
Unlocked-disabled,automaticInService &
notInstalled (ETSI)
Insert a valid card. OOS-AU,AINS & SWDL (ANSI)
Unlocked-disabled,automaticInService &
softwareDownload (ETSI)
Insert an invalid card. OOS-AU,AINS & MEA (ANSI)
Unlocked-disabled,automaticInService &
mismatchOfEquipment (ETSI)
Delete the card. OOS-AUMA,UAS & UEQ (ANSI)
Locked-disabled,unassigned & notInstalled (ETSI)

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
