Appendix B Administrative and Service States
B.2 Administrative States
B.2 Administrative States
Administrative states are used to manage service states. Administrative states consist of a PST and an
SST. Table B-3 lists the ANSI and ETSI administrative states supported by the ONS 15454. See
Table B-2 for SST definitions.
Note A change in the administrative state of an entity does not change the service state of supporting or
supported entities.
Table B-2 ONS 15454 Secondary States
ANSI Secondary
State ETSI Secondary State Definition
AINS automaticInService The entity is delayed before transitioning to the
IS-NR (ANSI)/Unlocked-enabled (ETSI) service state. The transition to
IS-NR/Unlocked-enabled depends on correction of conditions. Alarm
reporting is suppressed, but traffic is carried. Raised fault conditions,
whether or not their alarms are reported, can be retrieved on the Cisco
Transport Controller (CTC) Conditions tab or by using the TL1
RTRV-COND command.
DSBLD disabled The entity was manually removed from service and does not provide its
provisioned functions. All services are disrupted; unable to carry traffic.
FLT failed The entity has a raised alarm or condition.
MEA mismatchOfEquipment An improper card is installed. For example, an installed card is not
compatible with the card preprovisioning or the slot. This SST applies
only to cards.
MT maintenance The entity has been manually removed from service for a maintenance
activity but still performs its provisioned functions. Alarm reporting is
suppressed, but traffic is carried. Raised fault conditions, whether or not
their alarms are reported, can be retrieved on the CTC Conditions tab or
by using the TL1 RTRV-COND command.
SWDL softwareDownload The card is involved in a software and database download. This SST
applies only to cards.
UAS unassigned The card is not provisioned in the database. This SST applies only to cards.
UEQ
(Unequipped)
notInstalled The card is not physically present (that is, an empty slot). This SST applies
only to cards.
Table B-3 ONS 15454 Administrative States
ANSI Administrative
State (PST,SST)
ETSI Administrative State
(PST,SST) Definition
IS Unlocked Puts the entity in service.
IS,AINS Unlocked,automaticInService Puts the entity in automatic in-service.
