Cisco ONS 15454 DWDM Reference Manual

17-6
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 17 Performance Monitoring
17.2.2 Payload PM Window
• The Help button activates context sensitive help.
For a list of the payload PM provisioning options for all transponder and muxponder cards, refer to the
Cisco ONS 15454 DWDM Procedure Guide. The options selected in the Provisioning tab can affect the
parameters displayed in the Performance > Payload PM tab.
Table 17-2 lists the PM parameter types that appear when a particular port type is provisioned for a
transponder or muxponder card.
17.2.2.1 Payload PM SONET/SDH Window
Table 17-3 lists SONET/SDH layer near-end and far-end PM parameters listed in the card view on the
Performance > Payload PM > SONET or SDH tab. SONET/SDH layer PMs are available when the client
type is set to OC3/STM1, OC12/STM4, or OC48/STM16 on the TXP_MR_2.5G or when
OC192/STM64 is set on the TXP_MR_10G, TXP_MR_10E, TXP_MR_10E_C, TXP_MR_10E_L, or
ADM-10G on ONS 15454 SONET nodes. OC48/STM16 trunk PMs are available on MXP_MR_2.5G
and MXPP_MR_2.5G cards on ONS 15454 SONET or ONS 15454 SDH nodes. OC48/STM16 client
PMs are available on MXP_MR_10DME_C, MXP_MR_10DME_L, MXP_2.5G_10G,
MXP_2.5G_10E, MXP_2.5G_10E_C, and MXP_2.5G_10E_L cards on ONS 15454 SONET or
ONS 15454 SDH nodes. For PM definitions, see Table 17-29 on page 17-26 and Table 17-30 on
page 17-27.
Table 17-2 Transponder and Muxponder Port Type PM Provisioning Options
If this Port Type is Provisioned
1
1. The port type is provisioned from card view on the Provisioning > Pluggable Port Modules tab. For pluggable port module
(PPM) provisioning procedures, refer to the Cisco ONS 15454 DWDM Procedure Guide.
The Following PM Types are Activated
2
2. Performance monitoring parameters are displayed from the card view on the Performance tab.
SONET/SDH (including 10G Ethernet WAN Phy)
OC3/STM1
OC12/STM4
OC48/STM16
SONET or SDH PMs
10G Ethernet LAN Phy
10G FiberChannel
ONE_GE
FC1G
FC2G
FC1G ISL
FC2G ISL
FICON1G
FICON2G
FICON1G ISL
FICON2G ISL
ISC COMPAT
ISC PEER
Full remote monitoring (RMON) statistics
ESCON
DV6000
SDI_D1_VIDEO
HDTV
PASS_THRU
ETR_CLO
Payload PMs are not applicable to 2R port types.
