Cisco ONS 15454 DWDM Reference Manual

A-45
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.8.5 AD-4B-xx.x Card Specifications
A.8.5 AD-4B-xx.x Card Specifications
Table A-29 lists the unit names, band IDs, channel IDs, frequencies, and wavelengths assigned to the
two versions of the card.
Table A-29 AD-4B-xx.x Channel Allocation Plan by Band
Unit Name Band ID Channel ID Frequency (GHz) Wavelength (nm)
AD-4B-30.3 B30.3 30.3 195.9 1530.33
30.7 195.85 1530.72
31.1 195.8 1531.12
31.5 195.75 1531.51
31.9 195.7 1531.90
32.2 195.65 1532.29
32.6 195.6 1532.68
33.3 195.55 1533.07
B34.2 34.2 195.4 1534.25
34.6 195.35 1534.64
35.0 195.3 1535.04
35.4 195.25 1535.43
35.8 195.2 1535.82
36.2 195.15 1536.22
36.6 195.1 1536.61
37.0 195.05 1537.00
B38.1 38.1 194.9 1538.19
38.5 194.85 1538.58
38.9 194.8 1538.98
39.3 194.75 1539.37
39.7 194.7 1539.77
40.1 194.65 1540.16
40.5 194.6 1540.56
40.9 194.55 1540.95
B42.1 42.1 194.4 1542.14
42.5 194.35 1542.54
42.9 194.3 1542.94
43.3 194.25 1543.33
43.7 194.2 1543.73
44.1 194.15 1544.13
44.5 194.1 1544.53
44.9 194.05 1544.92
