A-44
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.8.4 AD-1B-xx.x Card Specifications
Table A-28 lists the range of wavelengths for the receive (express) band.
The AD-1B-xx.x card optical input and output power varies with amplifier output levels and the class of
transponder interfaces used. See Table 6-3 on page 6-3 through Table 6-6 on page 6-5 for this
information.
The AD-1B-xx.x card has the following additional specifications:
• Dimensions
–
Height: 12.650 in. (321.3 mm)
–
Width: 0.921 in. (23.4 mm) (The dimension of the finger gasket is not included)
–
Depth: 9.0 in. (228.6 mm)
Insertion loss
(express section)
All SOP and within whole
operating environmental range;
two connectors included
Exp Rx—COM Tx — 1.6 dB
All SOP and within whole
operating environmental range;
two connectors included, VOA set
at its minimum attenuation
COM Rx—Exp Tx — 2.2 dB
Insertion loss
(add section)
All SOP and within whole
operating environmental range;
two connectors included
Band Rx—COM Tx — 2.2 dB
VOA dynamic
range
——30—dB
Maximum optical
input power
——300—mW
Table A-27 AD-1B-xx.x Optical Specifications (continued)
Parameter Note Condition Min Max Unit
Table A-28 AD-1B-xx.x Transmit and Receive Dropped Band Wavelength Ranges
Tx (Dropped) Band
Rx (Express) Band
Left Side (nm) Right Side (nm)
B30.3 — Wavelengths 1533.825 or higher
B34.2 Wavelengths 1533.395 or lower Wavelengths 1537.765 or higher
B38.1 Wavelengths 1537.325 or lower Wavelengths 1541.715 or higher
42.1 Wavelengths 1541.275 or lower Wavelengths 1545.695 or higher
46.1 Wavelengths 1545.245 or lower Wavelengths 1549.695 or higher
50.1 Wavelengths 1549.235 or lower Wavelengths 1553.705 or higher
54.1 Wavelengths 1553.255 or lower Wavelengths 1557.745 or higher
58.1 Wavelengths 1557.285 or lower —
