Cisco ONS 15454 DWDM Reference Manual

A-43
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.8.4 AD-1B-xx.x Card Specifications
Table A-27 lists AD-1B-xx.x optical specifications.
AD-1B-50.1 B50.1 50.1 193.4 1550.12
50.5 193.35 1550.52
50.9 193.3 1550.92
51.3 193.25 1551.32
51.7 193.2 1551.72
52.1 193.15 1552.12
52.5 193.1 1552.52
52.9 193.05 1552.93
AD-1B-54.1 B54.1 54.1 192.9 1554.13
54.5 192.85 1554.54
54.9 192.8 1554.94
55.3 192.75 1555.34
55.7 192.7 1555.75
56.1 192.65 1556.15
56.5 192.6 1556.96
56.9 192.55 1556.96
AD-1B-58.1 B58.1 58.1 192.4 1558.17
58.5 192.35 1558.58
58.9 192.3 1558.98
59.3 192.25 1559.39
59.7 192.2 1559.79
60.2 192.15 1560.20
60.6 192.1 1560.61
61.0 192.05 1561.01
Table A-26 AD-1B-xx.x Channel Allocation Plan by Band (continued)
Unit Name Band ID Channel ID Frequency (GHz) Wavelength (nm)
Table A-27 AD-1B-xx.x Optical Specifications
Parameter Note Condition Min Max Unit
–1 dB bandwidth All SOP and within whole
operating environmental range
COM Rx—Band Tx
Band Rx—COM Tx
3.6 — nm
–1 dB bandwidth All SOP and within whole
operating temperature range
COM Rx—Exp Tx
Exp Rx—COM Tx
See
Table A-28.
nm
Insertion loss
(drop section)
All SOP and within whole
operating environmental range;
two connectors included, VOA set
at minimum attenuation
COM Rx—Band Tx — 3.0 dB

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
