Chapter 17 Performance Monitoring
17.2.3 OTN PM Window
Table 17-12 lists the OTN trunk-side PM parameters listed on the G.709 tab. OTN PMs are available
when ITU G.709 is enabled from the card view Provisioning > OTN > OTN Lines tab. OTN PMs are not
available on MXP_MR_2.5G and MXPP_MR_2.5G cards. For ITU G.709 section and path monitoring
PM definitions, see the “17.5 ITU G.709 and ITU-T G.8021 Trunk-Side PM Parameter Definitions”
section on page 17-21.
TXP_MR_2.5G G.709
FEC
FEC Thresholds
ADM-10G G.709
FEC
FEC Thresholds
GE_XP G.709
FEC
FEC Thresholds
10GE_XP G.709
FEC
FEC Thresholds
1. OTN provisioning is performed from card view on the Provisioning > OTN > OTN Lines, G.709 Thresholds, and FEC
Thresholds tabs.
Table 17-11 Transponder and Muxponder PM Provisioning Options (continued)
Card OTN Provisioning
1
Table 17-12 ITU G.709 OTN Trunk-Side PMs
OTN Layer (Near End and Far End)
1
1. Applicable to OCH facility.
Note
BBE-SM
BBER-SM
ES-SM
ESR-SM
FC-SM
SES-SM
SESR-SM
UAS-SM
FC-SM
ITU G.709 standard section monitoring
ITU-T G.8021
BBE-PM
BBER-PM
ES-PM
ESR-PM
FC-PM
SES-PM
SESR-PM
UAS-PM
ITU G.709 standard path monitoring
ITU-T G.8021

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
