Chapter 1 Shelf Assembly Hardware
1.4.3 Multiple Y-Cable Module Tray
Note The MXP_MR_10DME_C card is labeled 10DME-C on the card faceplate. The MXP_MR_10DME_L
card is labeled 10DME-L on the card faceplate.
1.4.3 Multiple Y-Cable Module Tray
Another option for Y-cable protection is the Y-cable module tray. Each tray holds up to 8 individual
Y-cable modules (Figure 1-15).
Figure 1-15 Y-Cable Protection Module Tray
The ports on these Y-cable modules are labelled according to their intended signal type (Client TX/RX,
TXP Working TX/RX, TXP Protect TX/RX). You can use the port label on the front of the tray to identify
the ports on each module (Figure 1-16).
144678
LC-LC cables
Y cable modules
