Chapter 6 Optical Add/Drop Cards
6.6 AD-1B-xx.x Card
Figure 6-15 AD-1B-xx.x Faceplate
For information on safety labels for the card, see the “6.2 Class 1M Laser Product Safety Lasers”
section on page 6-7.
Figure 6-16 shows a block diagram of the AD-1B-xx.x card.
AD-1B
-X.XX
FAIL
ACT
SF
RX
XX.X
TX
RX
EXP
TX
RX
COM
TX
96471
