Cisco ONS 15454 DWDM Reference Manual

A-27
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Appendix A Hardware Specifications
A.7.4 32WSS-L Card Specifications
– Height: 12.65 in. (321.3 mm)
– Width: 1.866 in. (47.4 mm) (The dimension of the finger gasket is not included)
– Depth: 9.00 in. (228.6 mm)
A.7.4 32WSS-L Card Specifications
The 32WSS-L card optical specifications are listed in Table A-12.
Note For power specifications, see Table A-2 on page A-6.
The 32WSS-L channel plan is shown in Table A-13. All 32WSS-L client interfaces must comply with
this plan.
Table A-12 32WSS-L Optical Specifications
Parameter Note Condition Min Typical Max Units
–0.1 dB bandwidth All SOP and within
whole operating
temperature range,
connectors
included, and for
maximum VOA
operating
attenuation.
EXP RX =>
COM TX
—+/–/57—pm
–0.25 dB bandwidth +/–/61 +/–/89 —
–0.5 dB bandwidth +/–91 +/–/116 —
–1.0 dB bandwidth +/–135 +/–/149 —
–0.1 dB bandwidth Add 1, 32 =>
COM TX
+/–32 +/–/69 —
–0.25 dB bandwidth +/–98 +/–/129 —
–0.5 dB bandwidth +/–135 +/–/161 —
–1.0 dB bandwidth +/–160 +/–/201 —
Insertion loss All SOP, any
optical switch state,
and within whole
operating
temperature range,
connectors
included.
EXP RX =>
COM TX
— 9.7 11.3 dB
COM RX =>
EXP TX
—1.41.6dB
Add 1, 32 =>
COM TX
—6.28.0dB
COM RX =>
DROP TX
6.0 8.0 8.5 dB
VOA dynamic range — EXP RX =>
COM TX
20 25 — dB
— Add 1, 32 =>
COM TX
25 25 — dB
Maximum optical
input power
— — 300 — — mW

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
