A.7.3 32WSS Card Specifications
The 32WSS card has the following additional specifications:
• Dimensions
Table A-11 32WSS Channel Plan
Channel
Number Band Channel ID Frequency (GHz) Wavelength (nm)
1 1 30.3 195.9 1530.33
2 31.2 195.8 1531.12
3 31.9 195.7 1531.90
4 32.6 195.6 1532.68
5 2 34.2 195.4 1534.25
6 35.0 195.3 1535.04
7 35.8 195.2 1535.82
8 36.6 195.1 1536.61
9 3 38.1 194.9 1538.19
10 38.9 194.8 1538.98
11 39.7 194.7 1539.77
12 40.5 194.6 1540.56
13 4 42.1 194.4 1542.14
14 42.9 194.3 1542.94
15 43.7 194.2 1543.73
16 44.5 194.1 1544.53
17 5 46.1 193.9 1546.12
18 46.9 193.8 1546.92
19 47.7 193.7 1547.72
20 48.5 193.6 1548.51
21 6 50.1 193.4 1550.12
22 50.9 193.3 1550.92
23 51.7 193.2 1551.72
24 52.5 193.1 1552.52
25 7 54.1 192.9 1554.13
26 54.9 192.8 1554.94
27 55.7 192.7 1555.75
28 56.5 192.6 1556.55
29 8 58.1 192.4 1558.17
30 58.9 192.3 1558.98
31 59.7 192.2 1559.79
32 60.6 192.1 1560.61

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
