Cisco ONS 15454 DWDM Reference Manual

7-67
Cisco ONS 15454 DWDM Reference Manual, R8.5
78-18343-02
Chapter 7 Reconfigurable Optical Add/Drop Cards
7.12.4 40-WXC-C Channel Plan
Additionally, the 40-WXC-C has two virtual diodes. Virtual diodes are monitor points for each physical
photodiode; they are identified with a physical diode relative to the way that the physical diode is
identified with one of the two interlink (ILK) ports. Table 7-38 lists the virtual diodes.
7.12.4 40-WXC-C Channel Plan
Table 7-39 shows the 40 ITU-T 100-GHz-spaced, C band channels (wavelengths) that are cross
connected by the 40-WXC-C card.
PDi4
1
TX COM TX port (that is,
per-channel output COM TX
power) up to 40 channels and
therefore 40 PDs
PD5 COM COM TX port (that is, total
output COM TX power)
1. i indicates any channel from 01 through 40.
Table 7-37 40-WXC-C Physical Photodiode Port Calibration (continued)
Physical
Photodiode CTC Type Name Calibrated to Port(s)
Table 7-38 40-WXC-C Virtual Photodiode Port Calibration
Virtual
Photodiode CTC Type Name Calibrated to Port(s)
VPD1 COM COM RX port (total input
COM RX power)
VPD2 EXP EXP TX port (total output
EXP TX power)
Table 7-39 40-WXC-C Channel Plan
Band ID Channel Label Frequency (GHz)
Wavelength
(nm)
Ch. 0
1
29.5 196 1529.55
B30.3 30.3 195.9 1530.33
31.1 195.8 1531.12
31.9 195.7 1531.90
32.6 195.6 1532.68
33.4 195.5 1533.47
B34.2 34.2 195.4 1534.25
35.0 195.3 1535.04
35.8 195.2 1535.82
36.6 195.1 1536.61
37.4 195 1537.40

Cisco ONS 15454 DWDM Specifications

General

Chassis Type	DWDM
Form Factor	Rack-mountable
Slots	17
Storage Temperature	-40 to 158°F (-40 to 70°C)
Relative Humidity	5% to 95% non-condensing
Power Supply	AC or DC
Cooling	Internal fans
Operating Temperature	23 to 104°F (-5 to 40°C)
Altitude	0 to 6500 ft (0 to 1981 m)
Safety Compliance	EN 60950-1
EMI Compliance	FCC Part 15
